Drawing the FSM for the Receiver Side of Protocol RDT 3.0

Reliable data transfer is a cornerstone of network communication. Protocols like RDT (Reliable Data Transfer) are designed to ensure that data packets arrive correctly and in order, even in the face of unreliable channels. RDT 3.0, a significant improvement over its predecessors, introduces mechanisms to handle both bit errors and packet loss. This article delves into the intricacies of the receiver side of RDT 3.0, providing a detailed explanation and a comprehensive Finite State Machine (FSM) diagram to illustrate its behavior.

Understanding RDT 3.0

Before diving into the FSM, let's review the key features of RDT 3.0. Unlike simpler protocols, RDT 3.0 accounts for both lost packets and corrupted packets. It achieves reliability through:

• Sequence Numbers: Each packet carries a sequence number (0 or 1 in RDT 3.0) to distinguish it from other packets.
• Checksums: A checksum is included in each packet to detect bit errors during transmission.
• ACKnowledgements (ACKs): The receiver sends ACK packets to acknowledge the successful receipt of data packets. These ACKs also carry the sequence number of the next expected packet.
• Timeout and Retransmission: The sender maintains a timer. If an ACK isn't received within the timeout period, the sender retransmits the packet.

This robust approach ensures that data arrives correctly and completely, even under challenging network conditions. The receiver plays a crucial role in this process, diligently verifying packets and sending appropriate ACKs.

The Receiver's Role in RDT 3.0

The receiver's primary responsibility is to:

1. Receive Packets: The receiver continuously listens for incoming data packets.
2. Check Checksum: Upon receiving a packet, the receiver calculates the checksum and compares it to the checksum received in the packet. If they don't match, the packet is discarded as corrupted.
3. Verify Sequence Number: The receiver checks the sequence number of the received packet. If the sequence number matches the expected sequence number, the packet is accepted; otherwise, it's discarded (as out of order).
4. Send ACK: If a packet is correctly received, the receiver sends an ACK packet with the sequence number of the next expected packet. This ACK acknowledges the successful reception and guides the sender's expectations.
5. Handle Timeouts (implicitly): While the receiver doesn't explicitly manage timers, its actions indirectly contribute to the sender's timeout mechanism. Failure to receive a correctly sequenced and checksummed packet (and the subsequent lack of an ACK) ultimately triggers the sender's retransmission.

Constructing the FSM for the RDT 3.0 Receiver

The FSM diagram represents the receiver's states and transitions based on received events. The states reflect the receiver's expectation of the next packet, and the transitions are triggered by the reception of packets and the subsequent actions.

States:

• Wait0: The receiver is expecting a packet with sequence number 0.
• Wait1: The receiver is expecting a packet with sequence number 1.

Events:

• 0: Reception of a packet with sequence number 0.
• 1: Reception of a packet with sequence number 1.
• 0_corrupt: Reception of a corrupted packet with sequence number 0.
• 1_corrupt: Reception of a corrupted packet with sequence number 1.

Transitions:

The following table outlines the transitions between states based on the events:

The FSM Diagram (Textual Representation)

Due to the limitations of Markdown in creating visual diagrams, a textual representation of the FSM is provided below. This representation captures the essence of the FSM, allowing you to visualize the transitions.

               +-------+
               | Wait0 |
               +-------+
                  |
                  V
       0 -------->+-------+
       |          | Wait1 |
       |          +-------+
       |                  |
       |                  V
       |         1 -------->+-------+
       |         |          | Wait0 |
       |         |          +-------+
       +---------+          ^
         |                   |
         |   0_corrupt      |   1_corrupt
         |                   |
         V                   |
       +-------+             |
       | Wait0 |<-----------+
       +-------+
         |
         |   0_corrupt
         |
         V
       +-------+
       | Wait1 |<-------- 1_corrupt
       +-------+

Note: The optional ACKs sent upon receiving corrupted packets are crucial for prompt retransmission by the sender, reducing the latency of error recovery. The absence of an ACK means there was no successful reception. This subtle difference significantly improves the efficiency of the protocol.

Detailed Explanation of Transitions

Let's analyze a few key transitions to further understand the receiver's behavior:

Transition 1: Wait0 -> Wait1 (Event: 0)

• The receiver is in the Wait0 state, expecting a packet with sequence number 0.
• It receives a packet with sequence number 0, and the checksum verifies correctly.
• The receiver delivers the data contained within the packet to the upper layer application.
• The receiver sends an ACK packet with sequence number 1, indicating that it's now expecting a packet with sequence number 1. The state transitions to Wait1.

Transition 2: Wait0 -> Wait0 (Event: 1)

• The receiver is in the Wait0 state.
• It receives a packet with sequence number 1. This is out of order.
• The receiver discards the packet because it was not expecting a packet with sequence number 1 in this state. The state remains Wait0.

Transition 3: Wait0 -> Wait0 (Event: 0_corrupt)

• The receiver is in the Wait0 state.
• It receives a packet with sequence number 0, but the checksum verification fails. The packet is corrupted.
• The receiver discards the corrupted packet. Optionally, it can send an ACK(0) to inform the sender that this packet wasn't received correctly, avoiding unnecessary timeouts. The state remains Wait0.

Importance of ACKs and Timeout Mechanism (Sender Side)

Although this FSM focuses on the receiver, it's crucial to understand how it interacts with the sender's timeout mechanism. The sender relies on receiving ACKs within a specified time window. If no ACK is received (due to ACK loss or the receiver not sending an ACK because of a corrupt packet), the sender times out and retransmits the packet. The receiver’s actions (sending or not sending an ACK) are vital to the success of this mechanism.

Conclusion

The FSM for the RDT 3.0 receiver elegantly captures the logic involved in reliable data transfer. By meticulously checking sequence numbers and checksums, and by sending appropriate ACKs, the receiver ensures data integrity and contributes significantly to the overall reliability of the RDT 3.0 protocol. Understanding this FSM is fundamental to comprehending how reliable data transmission is achieved in network communication. The optional inclusion of ACKs on receiving corrupted packets offers a more proactive approach compared to simply ignoring corrupt packets. This proactive sending of ACKs contributes to a more responsive and efficient error-recovery mechanism, minimizing delays and ensuring timely communication. This detailed explanation, along with the provided textual representation of the FSM, should enable a thorough understanding of the receiver side's functionality within the RDT 3.0 protocol.
